REVBOT QUICK WIRING FUSE BOX NEXUS 4

Smart 12V Power Distribution for Motorcycles & Vehicles

The REVBOT Quick Wiring Fuse Box NEXUS 4 is a compact and practical 4-channel electrical power distribution system designed for motorcycles, cars and other compatible 12V vehicles.

It allows multiple electrical accessories to be connected through a single centralized fuse box instead of connecting every accessory separately to the battery. This helps create a cleaner, safer and more organized wiring setup, while individual fuse protection helps protect each connected circuit.

The NEXUS 4 is ideal for riders using multiple accessories such as auxiliary lights, USB chargers, GPS units, mobile charging systems and other compatible 12V electrical equipment.

Key Features

• 4 independent accessory output circuits

• 12V DC operating system

• Maximum total current capacity: 20A

• Individual replaceable blade fuse protection

• Individual LED circuit status indicators

• Blue LED indicates normal powered operation

• Red LED helps identify a blown/faulty fuse

• Direct battery power connection

• ACC/ignition trigger connection

• Compact PC housing

• Helps reduce battery terminal wiring clutter

• Makes accessory wiring easier to organize and troubleshoot

• Suitable for motorcycles, cars and compatible 12V vehicles

4-Channel Power Distribution

The NEXUS 4 provides four separate output channels — NO.1, NO.2, NO.3 and NO.4.

Each channel can be used for an individual electrical accessory, allowing you to organize several accessories through one central distribution point.

This is especially useful on adventure and touring motorcycles where multiple accessories are commonly installed.

Individual Fuse Protection

Each output circuit is independently protected by a replaceable blade fuse.

If one connected accessory develops a fault or draws excessive current, the corresponding fuse can disconnect that circuit. This makes troubleshooting easier and helps protect the electrical wiring.

Supplied Fuse Configuration

• 1 × 2A Blade Fuse

• 3 × 5A Blade Fuses

The correct fuse rating should always be selected according to the electrical requirement of the connected accessory.

LED Status Indicator System

Each circuit features an LED indicator that provides a quick visual indication of its operating condition.

Blue LED: Circuit powered / normal operation
Red LED: Fuse fault / blown fuse indication

This allows the rider or installer to quickly identify which circuit may require inspection without checking every accessory individually.

Battery + ACC Wiring System

The NEXUS 4 uses a simple power and ignition-trigger wiring configuration.

Red Wire: Battery Positive (+)
Black Wire: Battery Negative / Ground (-)
ACC Wire: Switched ignition/ACC source
NO.1–NO.4: Individual accessory output connections

The ACC trigger allows the fuse box to work with the vehicle's ignition-switched electrical system, helping prevent accessories from remaining powered unnecessarily when the vehicle is switched off.

Ideal for Multiple Accessories

The REVBOT NEXUS 4 can be used to manage compatible 12V accessories such as:

• Auxiliary / fog lights

• Mobile chargers

• USB charging ports

• GPS / navigation systems

• Dash cameras

• Auxiliary displays

• Heated accessories

• Other compatible 12V motorcycle or automotive equipment

The total combined electrical load of all connected accessories must remain within the 20A maximum rating.

Cleaner Motorcycle Wiring

Installing several electrical accessories directly on the battery can lead to multiple terminals, tangled wiring and difficult troubleshooting.

The NEXUS 4 provides a centralized connection point, helping achieve a cleaner installation:

Battery → NEXUS 4 Fuse Box → Individual Fuse → Accessory

This arrangement makes future accessory installation, maintenance and troubleshooting much easier.

Compact & Practical Design

The compact housing makes the NEXUS 4 suitable for installation in limited-space locations such as:

• Under the motorcycle seat

• Near the battery compartment

• Behind suitable side panels

• Inside protected electrical areas

The unit should always be installed in a secure, dry, and protected location.

Product Specifications

Package Contents

• 1 × REVBOT Quick Wiring Fuse Box NEXUS 4

• 1 × Main Wiring Cable

• 1 × 2A Blade Fuse

• 3 × 5A Blade Fuses

• 2 × Cable Ties

• 3 × Cable Fixing Clips

• 1 × Round Terminal Cable

Installation Guidelines

Before installation, disconnect the vehicle battery and confirm the correct positive, negative and ACC wiring points.

Mount the fuse box securely in a location protected from direct water exposure, excessive heat and moving components. Route all cables carefully and ensure that connections are properly tightened.

The total electrical consumption of all connected accessories must not exceed 20A.

For the best installation and electrical safety, professional installation is recommended if you are unfamiliar with motorcycle or automotive wiring.

Important Safety Information

The NEXUS 4 is designed for 12V electrical systems only.

Do not exceed the maximum 20A total current capacity. Always use correctly rated fuses, avoid installing the product in areas exposed directly to water, and inspect all electrical connections before operating the vehicle.

Incorrect wiring, oversized fuses or excessive electrical load may damage the connected accessories or vehicle electrical system.

Warranty

1-Year Company Warranty

The REVBOT Quick Wiring Fuse Box NEXUS 4 comes with a 1-year warranty from the company.

Warranty is applicable according to company warranty terms and conditions. Damage caused by incorrect installation, misuse, unauthorized modification, incorrect wiring or electrical overload may not be covered.

Keep the original purchase invoice for warranty support.

Why Choose REVBOT NEXUS 4?

The NEXUS 4 is designed for riders who want to add multiple electrical accessories without creating a complicated wiring system around the battery.

With four individually protected circuits, LED status monitoring, ACC control and a maximum 20A capacity, it provides a clean and convenient solution for managing motorcycle and automotive accessories.

One Fuse Box. Four Circuits. Cleaner Wiring. Better Protection.
